LINS688D High Precision IMU

Range: Accelerometer ± 20g Gyroscope ± 450°/s Zero bias instability： Accelerometer 20μg Gyroscope 0.5°/h

关键词:

Category:

Ten-Axes

key word: LINS688D High Precision IMU

E-mail:

fox.zhao@lins-tech.com

Inquiry

Details

LINS688D is a small volume, overload resistance of strong inertial measurement unit. It can be used for the precise navigation, control, and dynamic measurement of the carrier. The product uses the high-precision MEMS inertial device, has high reliability and high hardness, and has the ability to accurately measure the angular speed and acceleration information of the mobile carrier in the harsh environment.

LINS688D built-in three-axis gyroscope and three-axis accelerometer are used to measure the triaxial angular rate and triaxial acceleration of the carrier. The gyroscope and accelerometer data after error compensation (including temperature compensation, non-position compensation, misalignment angle compensation, nonlinear compensation, etc.) are output through the serial port according to the agreed communication protocol.

Main features:

▪ High-precision MEMS equipped with 3-axis accelerometer, 3-axis gyroscope， 3-axis magnetometer and a digital barometer

▪ Range: Acce ± 20g, Gyro ± 450°/s

▪ Communication interface: SPI

▪ High output frequency: 2,000 Hz

▪ Operating temperature: -40°C~ +85°C

▪ Small size: 44 * 47 * 14mm
