LINS510 High Precision Inertial Measurement Unit
关键词:
Category:
key word: LINS510 High Precision Inertial Measurement Unit
Details
LINS510 is a durable industrial grade high-performance inertial measurement unit, based on MEMS accelerometers and gyroscopes, providing customers with a cost-effective solution.
The LINS510 inertial measurement unit has a small volume and light weight, and adopts an ultra durable and compact aluminum alloy shell. It has high reliability in harsh environments and has been widely used in dynamic control systems and attitude systems such as unmanned aerial vehicles(UAV) and remotely Operated Vehicles (ROV)，smart agriculture, mechanical control, platform stabilization , AGV, robots, etc.
Main features:
▪ Output of 3-axis gyroscope and 3-axis accelerometer
▪ Data output rate: 200-1000Hz
▪ Range: gyroscope ± 320°/s, accelerometer ± 18g
▪ Zero bias instability: gyroscope 0.5 °/h, accelerometer 20ug
▪ Small size: 22.4 * 22.4 * 9.0 mm
▪ Lightweight: 10g
▪ Wide temperature range: -40 ℃~+85 ℃
√ Products design aimed for high reliability，Effective researching and development for adaptiveness.
√ Specialized manufacturing equipment and devices, Rigorous procedure and quality assurance.
√ Dedicated to deliver high quality products to our clients.
√ Years of experiences in perfecting our products , positive feedback from over a thousand users.
√ Cutting-Edge calibration technology,fast and professional customer support.
√ Prioritize in providing satisfactory services.
Typical applications:
Product indicators：
|
Technical Index |
Design accuracy |
Remarks |
|
|
Gyroscope |
Accelerometer |
||
|
IMU Parameter |
|||
|
• Dynamic measuring range: X, Y, Z |
±320°/s |
±18g |
|
|
• Zero bias instability |
0.5 °/h |
20μg |
Allan variance |
|
• Random walk |
0.03 °/√ h |
0.05m/s/√ h |
|
|
• Zero bias stability |
2°/h |
80μg |
10s average@25℃ |
|
• Scale factor nonlinearity |
100ppm |
100ppm |
Acc Range： ±1 g |
|
• Alignment error |
100ppm |
100ppm |
|
|
• Bandwidth |
268Hz |
|
|
|
• Output Data Rate |
200Hz |
Maximum： 1000Hz |
|
|
Electrical characteristics |
|||
|
• Voltage |
5V DC |
|
|
|
• Power consumption |
0.5W |
|
|
|
• Communication interface |
RS422 |
921600 bps configurable |
|
|
Structural characteristics |
|||
|
• Size |
22.4 * 22.4 * 9mm |
|
|
|
• Weight |
10g |
|
|
|
Use environment |
|||
|
• Operating temperature |
-40°C~ +85 °C |
|
|
|
• Storage temperature |
-55°C~ +105 °C |
|
|
|
• Vibration |
6.06g（20-2000Hz） |
|
|
|
• Impact |
1000g / 0.5ms |
|
|
