LINS-F3X90 Three-axis fiber optic gyroscope
关键词:
Category:
key word: LINS-F3X90 Three-axis fiber optic gyroscope
Details
LINS-F3X90 is an inertial product developed for navigation guidance, attitude measurement and control systems of small missiles and guided bombs.
It consists of three all solid state fiber optic gyroscopes, three quartz accelerometers, and a data packaging board. It measures the angular velocity and linear acceleration of the carrier's motion, providing information for the carrier's attitude and navigation control. The measurement results are output through the RS422 serial port.
Main features:
√ 12 step quality control, super reliable, with more features
√ Using original branded parts, high-quality materials, and competitive prices
√ True and accurate after calibration, with perfect performance
√ Successful applications in dozens of fields, with over 1000 customers currently using them
▪ High precision three-axis fiber optic gyroscope
▪ Range： ±500°/s
▪ Zero bias stability：<0.1°/h
▪ Size ：90 x 90 x 78 (mm)
▪ Weight：850 ± 50g
▪ Working temperature: -40°C to +65°C
Typical applications:
Parameters：
|
Indicator items |
Parameter indicators |
Remarks |
||
|
F3X90H |
F3X90M |
F3X90L |
||
|
Accuracy index |
||||
|
• Range: X, Y, Z (°/s） |
±500 |
|
||
|
• Zero bias stability (°/h） |
0.10 |
0.20 |
0.30 |
1σ , 10s average |
|
• Zero bias repeatability (°/h） |
0.10 |
0.20 |
0.30 |
|
|
• Scale factor nonlinearity （ppm） |
30 |
50 |
50 |
1σ , room temperature |
|
• Scale factor repeatability （ppm） |
30 |
50 |
50 |
1σ , room temperature |
|
• Resolution (°/s） |
0.2 |
|
||
|
• Bandwidth（ Hz） |
200 |
|
||
|
• Quartz accelerometer |
configurable |
|
||
|
Electrical characteristics |
||||
|
• Voltage |
24V DC |
|
||
|
• Communication interface |
RS422 |
|
||
|
Structural characteristics |
||||
|
• Size |
90 * 90 * 78mm |
|
||
|
• Weight |
850 ± 50g |
|
||
|
Use environment |
||||
|
• Operating temperature |
-40°C~ +65°C |
|
||
|
• Storage temperature |
-50°C~ +70°C |
|
||
|
• Vibration |
4.2g ，20Hz～2000Hz |
|
||
|
• Impact |
30g， 10ms |
Half sine wave |
||
